做中空玻璃、暖边条、幕墙付框的厂，铝条（间隔条）折弯精度直接决定打胶是否吃力、角部是否漏点、整窗 K 值达不达标。靠手动折弯机+模板，老师傅一天折千根也难免“回弹角歪、圆弧角发扁、连续框首尾对不上”。全自动铝条折弯机，是把“手感”变成“伺服参数”的机器。

For factories that produce insulated glass, warm edge strips, and curtain wall frames, the bending accuracy of aluminum strips (spacer strips) directly determines whether it is difficult to apply glue, whether there are missing points at corners, and whether the K value of the entire window meets the standard. By relying on manual bending machines and templates, even if the master folds thousands of pieces a day, it is inevitable that the rebound angle will be crooked, the arc angle will be flattened, and the end of the continuous frame will not match. The fully automatic aluminum strip bending machine is a machine that transforms "hand feel" into "servo parameters".

一、先分铝条类型再选机?

1、 First, classify the type of aluminum strip before selecting the machine

普通铝间隔条（6/9/12/16mm）：非常通用，自动送条+液压/伺服折角即可；

Ordinary aluminum spacer strip (6/9/12/16mm): the most universal, automatic strip feeding+hydraulic/servo bending angle is sufficient;

暖边条（不锈钢复合、PP/玻纤复合、超级间隔条）：材质回弹大、表面不能压伤，要柔性夹持+低噪折弯模具；

Warm edge strip (stainless steel composite, PP/fiberglass composite, super spacer strip): The material has a large rebound and the surface cannot be crushed. It requires flexible clamping and low-noise bending molds;

高框铝条/幕墙付框：框大、边数多，核心看非常大框尺寸和储条长度，不是只看“能折多厚”。

High frame aluminum strip/curtain wall frame: The frame is large and has many edges. The focus should be on the maximum frame size and storage strip length, not just on how thick it can be folded.

二、真正决定品质的是“送—夹—折—切”闭环?

2、 The true determinant of quality is the "send clip fold cut" closed-loop system

好机器不是折头力气大，而是：

A good machine is not one with strong bending force, but rather:

伺服送条精度 ±0.1mm，长框不累积误差；

Servo feeding accuracy ± 0.1mm, with no cumulative error in the long frame;

折弯缸/伺服臂带压力补偿，铝条厚度 0.3~0.5mm 切换不调半天；

Bending cylinder/servo arm with pressure compensation, aluminum strip thickness of 0.3-0.5mm can be switched without adjustment for half a day;

角部 R 角、连续框（一个铝条折出矩形框，不焊接）首尾搭接量可设；

The overlap amount at the beginning and end of the corner R and continuous frame (a rectangular frame folded from an aluminum strip without welding) can be set;

自动切角/自动卸框，和下段充干燥剂、打丁基胶线对接。

Automatic corner cutting/automatic frame unloading, and docking with the lower section of desiccant filling and butyl rubber line.

人工折一根 1.5m×1m 框要 3 分钟，自动机 20~40 秒出框，且四角对称。

It takes 3 minutes to manually fold a 1.5m × 1m frame, and the automatic machine takes 20-40 seconds to produce the frame, with symmetrical corners.

三、非常容易被漏看的隐性指标?

3、 The most easily overlooked implicit indicators

铝条表面压痕/划伤：模具材质和导向槽不达标，暖边条直接废；

Aluminum strip surface indentation/scratch: The mold material and guide groove do not meet the standards, and the warm edge strip is directly scrapped;

回弹补偿算法：不同合金状态（H24/H34）回弹角不同，没材料库就得一直试折；

Rebound compensation algorithm: Different alloy states (H24/H34) have different rebound angles, so if there is no material library, we have to keep trying to fold;

上条方式：盘条自动上料 vs 定尺条人工喂，产能差一倍；

Previous method: Automatic feeding of wire rod vs. manual feeding of fixed length wire rod, with a production capacity difference of twice;

软件：能不能存几百种窗型尺寸、扫码调参、和 ERP/玻璃切裁线联通。

Software: Can it store hundreds of window sizes, scan codes to adjust parameters, and connect with ERP/glass cutting lines.

四、和产线怎么搭才不卡脖子?

4、 How to connect with the production line without getting stuck

折弯机后面接“铝条灌装机（干燥剂）→ 传送→ 玻璃合片线”才叫自动化；只买折弯机不接上料和合片，工人还是两头跑。小厂先上单头自动折弯，日产超 800 樘再上升级连续框/双头/机器人码框。

After the bending machine is connected to the "aluminum strip filling machine (desiccant) → conveyor → glass laminating line", it is called automation; Only buying a bending machine without feeding and laminating, the workers still run at both ends. The small factory will first adopt single head automatic bending, and then upgrade to continuous frame/double head/robot code frame with a daily output of over 800 units.

全自动铝条折弯机不是“把铝条掰弯”，是把中空玻璃的角部气密、框型公差、材料损耗提前锁死在伺服系统里。铝条折得准，后面打胶才不补刀、整窗才不结露。

The fully automatic aluminum strip bending machine does not simply bend the aluminum strip, but locks the corner airtightness, frame tolerance, and material loss of the insulated glass in advance in the servo system. The aluminum strip is folded accurately, and the back is glued without a knife, and the entire window does not condense.
